The 24GHz Movement Monitoring Radar developed by Insightica is a millimeter wave radar that can accurately determine whether the room is occupied or unoccupied, which can be applied to community and family home care and indoor intelligent security. The radar has high sensitivity, compact shape and strong anti-interference capability.
This radar can achieve breath-level micro-movement detection within its signal coverage and accurately detect various micro-movement in the room, providing effective data information to support the realization of various intelligent scenes while realizing human sensing.
Breath-level micro-movement detection.
Realize synchronous sensing function of moving target and stationary target based on FM continuous wave radar technology.
Environmental calibration function, which automatically collects the basic information of the environment where it is located, realizes self-calibration of the judgment parameters, filters the interference of non-target signals, and makes detection more accurate.
Autonomous configuration of response sensitivity, supporting users to adjust the output sensitivity of the sensing signal according to actual needs and optimize detection time. State change testing time under extreme conditions: ≤ 0.5s.
Unaffected by temperature, humidity, noise, airflow, dust, Light, etc., suitable for harsh environments
Low output power, no harm to human body
Dynamic data sensing only, no privacy violation.
The product supports secondary development and system integration, and applies to a variety of scenario.
Linkage control: intelligent lighting, intelligent air conditioning, intelligent speakers, intelligent TV
Human detection: park clearing, home security
Energy saving and emission reduction: energy-saving control of home appliances, energy-saving control of office appliances (air conditioners, lights, etc.)
With the radar installed in the devices at home, it can real-time monitor indoor human activity status and then linked to home intelligent devices to adjust the work mode (on, off, standby, low-speed operation, intelligent lighting brightness adjustment, etc.) to achieve home appliance intelligence, building a real smart home life.
Smart home devices that can be linked include: smart lighting, smart air conditioners, smart speakers, smart TVs, and other smart home appliances.
For places that require personnel access monitoring, the radar can realize real-time monitoring of the presence of moving targets in the room, target activities, etc., and synchronize monitoring data information to the IoT platform, supporting the construction of the required security monitoring scenarios while effectively avoiding privacy breaching issues.
Applicable security monitoring scenarios include: home security, hotel management and monitoring, community recreation personnel monitoring, campus management, office monitoring, prison monitoring
Based on the effective detection of micro-movement objects by this radar, it can be applied in home, office or school environments to achieve energy-saving controls, including energy-saving control of home appliances, energy-saving control of office appliances (air conditioners, lights, etc.), and energy-saving control of street lights.
|Transmitting antenna beam width||Pitch plane||27||degree|
|Receiving antenna beam width||Pitch plane||27||degree|
|Motion Sensing Distance||12||m|
|Micro-motion Sensing Distance||7||m|
|Target Sensing Distance||12||m|
|Method||Level||Baud rate||Data bits||Parity Check||Stop bits|
